WASHERS
DIN 125
Flat Washers
Current norm: DIN 125, ISO 7089
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 125 Flat Washers are standard metric flat washers – a circular metal disc with a central hole. Typically used to distribute the load over a larger bearing surface either positioned below the head of a bolt or below the nut. This even distribution over a larger area reduces the chance of damaging the bearing surface. A washer could also be used if the outer diameter of a mating nut is smaller than the hole through which the screw is placed.
To get detailed information or to place an order, send us an e-mail.
.png){kind=small}
DIN 9021
Large Plain Washers
Current norm: DIN EN ISO 7093-1, ISO 7093
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 9021 Flat Fender Washers are round flat washers with a larger outer diameter (OD) approximately 3 x inner diameter (ID). These larger OD washers are typically used to distribute the load over a larger bearing surface than a standard flat washer. The washer is to be positioned below the head of a bolt or below the nut. This even distribution over a larger area reduces the chance of damaging the bearing surface. A washer could also be used if the outer diameter of a mating nut is smaller than the hole through which the screw is placed.
To get detailed information or to place an order, send us an e-mail.
DIN 127 B
Spring Washers
Current norm: DIN 127 B
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 127 Helical Spring Split Lock Washers are commonly used metric lock washers – It is a split metal ring that is bent into a helical shape. Split Lock Washers are a left hand helix and allow the nut to be tightened in a right hand direction only. When compressed by tightening the nut, the washer bites into the substrate and exerts a spring force between the bolt and the substrate creating frictional resistance to rotation. DIN 127 are available in two forms, type A and type B. Type DIN 127 A have bent up tang at both ends of the washer. Type B simply have square/straight ends.
To get detailed information or to place an order, send us an e-mail.
.png){kind=small}
DIN 128 A
Curved Spring Lock Washers
Current norm: DIN 128 A
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 128 Type A and B Spring Lock Washers are specialty spring lock washers – Both are split metal rings that are bent into a curved (Type A) or waved configuration (Type B). Unlike standard split helical spring lock washers, the DIN 128 lock washers are non-directionally specific allowing the screw and or nut to be tightened in a clockwise or counter-clockwise manner. When compressed by tightening the nut, the DIN 128 lock washer exert a spring force between the tightened bolt and the substrate creating frictional resistance to rotation.
To get detailed information or to place an order, send us an e-mail.
DIN 6796
Conical spring washers
Current norm: DIN 6796
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 6796 Conical Spring Washers for bolted connections are conical shaped washers that act as heavy duty spring discs when loaded in the axial direction. They are designed to be used in bolted connections where they help prevent loosening or unfastening of the connection due to thermal expansion/contraction and/or vibrational forces.
To get detailed information or to place an order, send us an e-mail.
DIN 435
Square taper washers for I Sections
Current norm: DIN 435
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 435 Square Taper Washers are wedge shaped square washers with an 8% taper. They have a single groove running the full length of the washer at the thick end perpendicular to the taper and is used primarily for I channel sections.
To get detailed information or to place an order, send us an e-mail.
DIN 434
Square Taper Washers for U Section
Current norm: DIN 434
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 434 Square Taper Washers are wedge shaped square washers with an 8% taper. They have two grooves running the full length of the washer perpendicular to the taper and is used primarily for U channel sections.
To get detailed information or to place an order, send us an e-mail.
DIN 6798 A
Serrated Lock Washers
Current norm: DIN 6798 A
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 6798 A are external toothed washers that can provide excellent locking. They are particularly effective on flat bearing surfaces that are larger than their outer diameter. Sizes from 3 to 16 mm feature overlapped teeth to ensure an excellent clamping.
To get detailed information or to place an order, send us an e-mail.
DIN 6798 J
Serrated Lock Washers (Internal Teeth)
Current norm: DIN 6798 J
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 6798 J are internal toothed washers that can guarantee excellent locking, in particular on non-flat bearing surfaces.
To get detailed information or to place an order, send us an e-mail.
DIN 137-B
Curved Spring Washers
Current norm: DIN 137
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 137 Type A and B Spring Lock Washers are specialty spring lock washers – Unlike standard split helical spring lock washers, the DIN 137 lock washers are uninterrupted formed disks in either a curved or waved configuration that are non-directional allowing the screw and or nut to be tightened in a clockwise or counterclockwise manner. When compressed by tightening the nut, the DIN 137 lock washers exert a spring force between the tightened bolt and the substrate creating frictional resistance to rotation.
To get detailed information or to place an order, send us an e-mail.
DIN 126
Curved Spring Lock Washers
Current norm: DIN 126
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
To get detailed information or to place an order, send us an e-mail.
DIN 6916
Plain Washers for Steel Construction
Current norm: DIN 6916
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
To get detailed information or to place an order, send us an e-mail.
Inch Flat Washers
Current norm: ASME
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
To get detailed information or to place an order, send us an e-mail.
Inch Spring Lock Washers
Current norm: ASME
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
To get detailed information or to place an order, send us an e-mail.
Tab Washers
(Lock Washers)
Current norm: DIN 93
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 93
To get detailed information or to place an order, send us an e-mail.
.png){kind=small}
Large Plain Washers
Current norm: DIN 134
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 134
To get detailed information or to place an order, send us an e-mail.
Flat Washers
Current norm: DIN 433, ISO 7092
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 433
To get detailed information or to place an order, send us an e-mail.
External Tab Washers
Current norm: DIN 432
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 432
To get detailed information or to place an order, send us an e-mail.
Flat Square Washers
Current norm: DIN 436
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 436
To get detailed information or to place an order, send us an e-mail.
Internal Tab Washers
Current norm: DIN 462
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 462
To get detailed information or to place an order, send us an e-mail.
Circlips Washer
- Retaining rings for shafts-
Current norm: DIN 471
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 471
To get detailed information or to place an order, send us an e-mail.
Sealing washers
Current norm: DIN 470
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 470
To get detailed information or to place an order, send us an e-mail.
External retaining rings with lugs
Current norm: DIN 983
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 983
To get detailed information or to place an order, send us an e-mail.
Circlip Ring Washer/Retaining Ring
Current norm: DIN 472
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 472
To get detailed information or to place an order, send us an e-mail.
Retaining Rings with Lugs for Bores (internal)
Current norm: DIN 984
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 984
To get detailed information or to place an order, send us an e-mail.
Shim Washers
Current norm: DIN 988
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 988
To get detailed information or to place an order, send us an e-mail.
Table Washers
Current norm: -
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
To get detailed information or to place an order, send us an e-mail.
Medium type washers for pins
Current norm: DIN EN 28738, ISO 8738
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 1440
To get detailed information or to place an order, send us an e-mail.
Disc Spring Washer
Current norm: DIN 2093
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 2093
To get detailed information or to place an order, send us an e-mail.
Washers for clamping devices
Current norm: DIN 6340
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 6340
To get detailed information or to place an order, send us an e-mail.
Retaining washers for shafts
Current norm: DIN 6799
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 6799
To get detailed information or to place an order, send us an e-mail.
Spring Lock Washers
Current norm: DIN 7980
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 7980
To get detailed information or to place an order, send us an e-mail.
Thick Flat Washer
Current norm: DIN 7349
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 7349
To get detailed information or to place an order, send us an e-mail.
Penny Washers
Current norm: DIN 125, ISO 7089
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
To get detailed information or to place an order, send us an e-mail.
Current norm: DIN 7993
Materials: Iron, Steel, Stainless Steel
Hardness: 100HV, 140HV, 200 HV, 300HV
Coatings: Plain, Zinc Plate, Zinc Flake, HDG
DIN 7993
To get detailed information or to place an order, send us an e-mail.
